1. Large 5 axis cnc router machine working size : X axis 4000mm, Y axis 8000mm, Z axis 1200-2000mm B axis 120 degrees C axis 320 degrees

2. The spindle power is 15-17kw, 24000rpm , HSK63F models for working on wood , styrofoam etc and some light metal

3. Guide rails are high precision from Taiwan HIWIN --good quality and good accuracy during working

4. 5 Axis cnc milling machine is taken with servo motors on X Y Z axis . Japan Yaskawa servo motors and motor reducer .

5. Control system are Taiwan Syntec with RTCP function ( five-axis compensation-Rotation tool center point feature for high precision processing on surface )

6. Strong machine frame steel welding thickness .

7. Front and back door for the machine . It is optional

8. Travel speed 40-45m/min. working speed is 15-20m/min

9. Professional engineers in MVIPCNC check the machine carefully and test the machine more than 48 hours .

10. All machine

Widely used in woodworking carving, mold processing, trimming and milling of household appliances, intensive repair of bathroom bags, aviation, motor cars, wind power, RVs, yachts, wooden houses, handicrafts and other modeling processing.
Processing of new materials such as PVC, PP, PE, foam, EPS, glass fiber, carbon fiber, resin, rubber and plastic, wood substitute, and light metals such as copper and aluminum polymers.
1. Die industry: Any sculpture of aluminum, foam, plastic, PVC, wood, fiberglass and other soft-metallic materials;
2. Mold industry: Any type car mold, boat mold, foundry mold, aviation mold, dia mold, etc;
3. Plate processing industry: Insulation, aluminium,plastic and chemical, the PCB, move the car body, bowing, track, anti-special board, epoxy, resin, ABS, PP, PE, and other carbon mixture;
